Watertite Conservation's 80l Tank System

The Watertite Tank System is designed for the INDIGENT USER. It serves as a neat and compact storage facility in side the home of the consumer, to ensure a continuous supply of water within the limit that is prescribed by government, minimum of 200L / day = 6kL / month. This gets controlled through the Smart Flow Valve in Round Box.

Image 01

Approx. Dimensions of tank.

Base dimensions:
Length: 786mm(internal), 990mm(external),
Width: 265mm (internal), 275mm(external),
Height: 442mm.

Lid dimensions:

Length: 773mm(internal), 806mm(external),
Width: 244mm(internal), 277.5mm(external),
Height: 8mm(internal), 15.3mm(external).



Technical Information

The 80ℓ  tank to be an INJECTION MOUDLING  tank that complies with the relevant SABS specification on materials used for potable water. The tank will be a horizontal (cistern like) whitetank of composite material to minimize algae growth in the tank.

The tank must serve as a LOCAL STORAGE facility that will ensure the supply of water at continuous flow. The tank must be fitted with a low-pressure plastic float valve to comply with S.A.B.S specifications and shower rose (which shower rose can be removed and sealed of by means of a plug, if not required), enclosed and sealed in such a manner that the tank can be enclosed and sealed with SIX V.O. SEALS. Tank must be fitted by means of 6x raw bolts. With a 15mm inlet and 15mm outlets threaded, with 20mm over flow.

Advantages:
This unique storage facility, is designed to supply clean water to INDIGENTS in side their homes, without having to collect water from rivers, dams or communal standpipes.

Delivers water on DEMAND at a CONTINUOUS FLOW.

The Tank gets installed in side the house, for protection against exposure to extreme weather conditions and to prevent the ingress of dust, insects and unwanted elements.

Tank is treated against the build-up of algae, and is in compliance with regard to materials and chemicals use in the manufacturing process. (Certificates and more detailed specifications available on request)
